Stauff NL-250-F-10-B/4 Replaces the Stauff NL250F10B
Stauff NL-250-F-10-B/4 Replaces the Stauff NL250F10B
NL-250-F-10-B/4
Stauff
Stauff NL250F10B
Stauff
Stauff NL250F10B
Description
Replacement Filter Element for Medium-Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 79,8 Inner Diameter (mm): 40,2 Length (mm): 249 Sealing: NBR, β ratio >200
Brand:
Stauff
Sort by:
Ships in 58 Days
€412,95
Price€412,95/each
Shipped Tuesday, 3 June
Order within 16hrs 38mins
Order within 16hrs 38mins
| UNITS | PER UNIT |
|---|---|
| 2 - 4 | €404,70 |
| 5 - 9 | €396,44 |
| 10+ | €388,18 |
1.46 kg
8421.99.90
Germany
Description
Replacement Filter Element for Medium-Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 79,8 Inner Diameter (mm): 40,2 Length (mm): 249 Sealing: NBR, β ratio >200Specification
| Style | DIN Pressure Filter |
| Efficiency 1 | 10µ @ β200 |
| Efficiency 2 | 12µ @ β1000 |
| Outer Diameter | 78.0 mm |
| Inner Diameter | 40.2 mm |
| Length | 248.0 mm |
| Media | Glass Fiber |
| Flow Direction | OUT-IN |
| Δ Collapse Pressure | 210 BAR |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
