Stauff NL-250-E-06-B/4 Replaces the Stauff NL250E06B4
Stauff NL-250-E-06-B/4 DIN Pressure Filter
NL-250-E-06-B/4
Stauff
Stauff
Brand:
Stauff
Sort by:
Description
Replacement Filter Element for Medium-Pressure Filters Micron Rating: 6 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 79,8 Inner Diameter (mm): 40,2 Length (mm): 249 Sealing: NBR, β ratio >200
Ships in 8 Weeks
€291,95
Price€291,95/each
Shipped Wednesday, 7 January
Order within 16hrs 36mins
Order within 16hrs 36mins
| UNITS | PER UNIT |
|---|---|
| 2 - 4 | €286,12 |
| 5 - 9 | €280,28 |
| 10 - + | €274,44 |
Germany
8421.99.90
1.68 kg
0.0015 m³
United Kingdom
8421.99.90
0.76 kg
0.0015 m³
Italy
8421.99.90
0.74 kg
0.002 m³
France
8421.99.90
Description
Replacement Filter Element for Medium-Pressure Filters Micron Rating: 6 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 79,8 Inner Diameter (mm): 40,2 Length (mm): 249 Sealing: NBR, β ratio >200Specification
| Style | DIN Pressure Filter |
| Media | Glass Fiber |
| Efficiency 1 | 5µ @ β200 |
| Efficiency 2 | 7µ @ β1000 |
| Outer Diameter | 78.0 mm |
| Inner Diameter | 40.5 mm |
| Length | 248.0 mm |
| Δ Collapse Pressure | 21 bar |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
Stauff Product
Genuine Stauff NL-250-E-06-B/4
Inspected to ISO 9001:2015
See Our Certification
Free 45-Day Returns
Return Policy
